Features
Delivers 200W power for charging
Charges AND balances Smart G2 batteries with one simple IC3® or IC5® connection — no separate balance lead needed
Auto Charge recognizes Smart battery charging parameters and begins safe, accurate charging automatically when connected
Charges virtually any RC battery (use Smart batteries to benefit from all charger features)
Smart software tracks and stores numerous Smart battery data
Includes IC3® and IC5® charging output ports — no separate adapters required to charge different Spektrum™ Smart batteries
An on-screen clock counts down remaining charge time until your Smart battery is fully charged and ready to use
Updated user interface features fresh, intuitive menus, icons and navigation tools, plus non-slip, easy to use buttons
USB input and output ports are included for updating firmware and charging secondary devices
ON/OFF switch eliminates the need to plug in and unplug the power cord for on/off control
Detachable power cord makes transporting more convenient
Includes an efficient, low-noise cooling fan
Compact size and sleek, sturdy case fits well on a workbench and in pit or field bags
Handy rubber grips on case make it easier to plug in and remove batteries
IC3® and IC5® connectors are backwards compatible with EC3™ and EC5™ connectors
Overview
With its 200W power, improved user interface, and ability to fast charge Smart batteries on either the IC3® or IC5® integrated output port, the S1200 charger offers a versatile and truly hassle-free charging experience. You can charge virtually any RC battery with the S1200 charger. Use it together with Smart G1 or G2 batteries and you'll be amazed by its incredible functionality and performance.
The S1200 Smart G2 AC Charger makes battery charging the easiest it has ever been. Its Auto Charge feature recognizes your Smart battery's parameters, such as chemistry type and charge rate, and begins safe, correct charging automatically when the charge lead is connected. A clock on the charger's screen counts down the time until your Smart battery is fully charged and ready to use.
Balancing Smart G2 batteries is just as simple. The S1200 charger will balance your Smart G2 LiPo packs through the same, single IC connection used for charging. No separate, confusing balance leads are required.
The S1200 Smart G2 AC Charger's updated interface features fresh, intuitive menus, icons, and navigation tools. Its clear, easily understandable indicators of Smart battery history and performance provide the information you need to make the best decisions about your batteries when putting gear together for a day at the field or track.
USB input and output ports enable you to charge secondary devices and to update the charger's firmware so you always have the latest version. The S1200 Smart G2 AC Charger also includes an ON/OFF switch, cooling fan, detachable power cord, and sleek case with rubber grips that fits perfectly on your workbench and in your pit or field bag.
Product Specifications
Amp Meter Yes
Application RC model battery charger
Battery Balance Connector JST-XH
Battery Temperature Monitoring Yes
Charge Protection Circuitry Yes
Discharge 0.1 - 1.5A (10W Max)
Display 2.4" 320 x 240 IPS LCD
Hard Case Yes
Input Voltage 100-240V AC
Integrated Balancing Yes - Internal Balancer & Internal Adapter
Maximum Charge Rate 15.0A
Maximum Continuous Discharge Current 10W
Normal/Standard Charge Current 0.1 - 15.0A, adjustable in 0.1A increments
Number of Cells 1 - 6S Li-Ion/LiPo/LiFe, 1 - 16S NiCd/NiMH, 1 - 12S Pb
Output Connector IC3 and IC5 selectable
Over Current Protection Yes
PC Connectivity Yes
Peak Detection Yes
Product Height 4.1" (104 mm)
Product Length 5.7" (145 mm)
Product Weight 2.2lbs (1015g)
Product Width 5.7" (145 mm)
Programmable Yes
Reverse Polarity Protection Yes
Safety Timer Yes
Selectable Charge Rate Yes
Short Circuit Protection Yes
Software Updates Yes
Technology Smart
Thermal Protection Yes
Voltage Meter Yes
